6. After confirming the Striped set, a summary of the Striped set will be displayed similar to the
following screen image:
RAID Configuration Utility - Silicon Image Inc. Copyright © 2002
Create RAID set Press <Enter> to create RAID
Delete RAID set set
Rebuild Mirrored set
Resolve Conflicts
*0 PM Manufacturer Model XXXXXMB
1 SM Manufacturer Model XXXXXMB
*Set0 SiI Striped Set PM XXXXXXMB
0 Manufacturer Model chunk size XXK
1 Manufacturer Model chunk size XXK
6HOHFW0HQX
ESC Previous Menu
Enter Select
Ctrl-E Exit
* First HDD
7. Press <Ctrl-E> to exit the RAID Configuration Utility.
8. Press <Y> to confirm exit and proceed with operating system setup.
Creating a Mirrored Set (RAID 1)
Automatic Configuration
To automatically configure a mirrored set, highlight the Auto Configuration option using the
up-down arrow keys and press <Enter>.
✏
NOTE
The Auto Configuration option will assign the drive “0” (drive on the primary SATA channel) as
the source drive and drive “1” (drive on the secondary SATA channel) as the target drive. If you
wish to select the drive assignments for the source and target drives, choose the Manual
Configuration option.
