Intel Desktop Board D975XBX2 Technical Product Specification
14
For information about Refer to
Available configurations for the board Section 1.2, page 17
1.1.3 Board Layout
Figure 1 shows the location of the major components.
Figure 1. Desktop Board Components
Table 3 lists the components identified in Figure 1.
