Product Description
17
1.2 Online Support
To find information about… Visit this World Wide Web site:
Intel Desktop Board D975XBX2
under “Desktop Board Products” or
“Desktop Board Support”
http://www.intel.com/design/motherbd
http://support.intel.com/support/motherboards/desktop
Available configurations for the
Desktop Board D975XBX2
http://developer.intel.com/design/motherbd/bx2/bx2_available.htm
Processor data sheets http://www.intel.com/design/litcentr
ICH7-R/ICH7-DH addressing http://developer.intel.com/design/chipsets/datashts
Custom splash screens http://intel.com/design/motherbd/gen_indx.htm
Audio software and utilities http://www.intel.com/design/motherbd
LAN software and drivers http://www.intel.com/design/motherbd
1.3 Processor
The board is designed to support the following processors:
• Intel Core 2 Extreme Processor in an LGA775 socket with a 1066 MHz system bus
• Intel Core 2 Duo Processor in an LGA775 socket with a 1066 MHz system bus
• Intel Pentium Processor Extreme Edition in an LGA775 socket with a 1066 or
800 MHz system bus
• Intel Pentium 4 Processor Extreme Edition in an LGA775 socket with a 1066 MHz
system bus
• Intel Pentium D Processor in an LGA775 socket with an 800 MHz system bus
• Intel Pentium 4 Processor in an LGA775 socket with an 800 MHz system bus
See the Intel web site listed below for the most up-to-date list of supported
processors.
For information about… Refer to:
Supported processors for the board http://www.intel.com/design/motherbd/bx2/bx2_proc.htm
CAUTION
Use only the processors listed on web site above. Use of unsupported processors can
damage the board, the processor, and the power supply.
#
INTEGRATOR’S NOTE
This board has specific requirements for providing power to the processor. Refer to
Section
2.7.2.1 on page 63 for information on power supply requirements for this
board.
