2.6 PCI Conventional Interrupt Routing Map
This section describes interrupt sharing and how the interrupt signals are connected
between the PCI Conventional bus connectors and onboard PCI Conventional devices.
The PCI Conventional specification describes how interrupts can be shared between
devices attached to the PCI Conventional bus. In most cases, the small amount of
latency added by interrupt sharing does not affect the operation or throughput of the
devices. In some special cases where maximum performance is needed from a device,
a PCI Conventional device should not share an interrupt with other PCI Conventional
devices. Use the following information to avoid sharing an interrupt with a PCI
Conventional add-in card.
PCI Conventional devices are categorized as follows to specify their interrupt grouping:
• INTA: By default, all add-in cards that require only one interrupt are in this
category. For almost all cards that require more than one interrupt, the first
interrupt on the card is also classified as INTA.
• INTB: Generally, the second interrupt on add-in cards that require two or more
interrupts is classified as INTB. (This is not an absolute requirement.)
• INTC and INTD: Generally, a third interrupt on add-in cards is classified as INTC
and a fourth interrupt is classified as INTD.
The ICH7-R/ICH7-DH has eight Programmable Interrupt Request (PIRQ) input signals.
All PCI Conventional interrupt sources either onboard or from a PCI Conventional
add-in card connect to one of these PIRQ signals. Some PCI Conventional interrupt
sources are electrically tied together on the board and therefore share the same
interrupt.
Table 15 shows an example of how the PIRQ signals are routed.
Table 15. PCI Interrupt Routing Map
ICH7-R/ICH7-DH PIRQ Signal Name
PCI Interrupt Source
PIRQA PIRQB PIRQC PIRQD PIRQE PIRQF PIRQG PIRQH
PCI bus connector 1 INTD INTA INTB INTC
PCI bus connector 2 INTD INTC INTA INTB
IEEE-1394a controller INTA
Discrete SATA Controller INTA
NOTE
In PIC mode, the ICH7-R/ICH7-DH can connect each PIRQ line internally to one of the
IRQ signals (3, 4, 5, 6, 7, 9, 10, 11, 12, 14, and 15). Typically, a device that does not
share a PIRQ line will have a unique interrupt. However, in certain interrupt-
constrained situations, it is possible for two or more of the PIRQ lines to be connected
to the same IRQ signal. Refer to
Table 14 for the allocation of PIRQ lines to IRQ
signals in APIC mode.
PCI interrupt assignments to the USB ports, Serial ATA ports, and PCI Express ports
are dynamic.
