Resume on Ring enables telephony devices to access the computer when it is in a
power-managed state. The method used depends on the type of telephony device
(external or internal).
NOTE
The use of Resume on Ring and Wake from USB technologies from an ACPI state
requires an operating system that provides full ACPI support.
1.13.2.1 Power Connector
When an ACPI-enabled system receives the appropriate command, the power supply
removes all non-standby voltages.
When resuming from an AC power failure, the computer returns to the power state it
was in before power was interrupted (on or off). The computer’s response can be set
using the Last Power State feature in the BIOS Setup program’s Boot menu.
For information about Refer to
The location of the main power connector Figure 20, page 59
The signal names of the main power connector Table 24, page 63
1.13.2.2 Fan Headers
The function/operation of the fan headers is as follows:
• The fans are on when the board is in the S0 or S1 state.
• The fans are off when the board is off or in the S3, S4, or S5 state.
• Each fan header is wired to a fan tachometer input of the hardware monitoring and
fan control ASIC
• All fan headers support closed-loop fan control that can adjust the fan speed or
switch the fan on or off as needed
• All fan headers have a +12 V DC connection
For information about Refer to
The location of the fan headers Figure 20, page 59
The location of the fan headers and sensors for thermal monitoring Figure 13, page 38
The signal names of the fan headers Section 2.7.1.1, page 57
