Intel Education Content Access Point User Manual

Getting Started for Admins
Intel® Education Content Access Point
User Manual January 2015
10 Document Number: 331819-001EN
1
System LED status
2
3G/4G/LTE LED status
3
Power button
4
Factory reset button
5
Wall-mount holes
6
Wi-Fi MAC (WFM), Ethernet (LNM) MAC address label
7
Power plug
8
WAN Ethernet port
9
WAN Ethernet link LED status
10
WAN Ethernet activity LED status
11
USB 3.0 port
12
Hard drive
13
3G/4G/LTE micro-SIM slot
14
Battery
2.3.1 LEDs
Table 1: System LED status
Device state
Color
Description
Off
None
The device is powered off
Fast pulsing then solid
Blue
The device is powered on and booting up
Slow pulsing (“breathing”)
Blue
The device has booted and is functioning normally
Slow pulsing
Blue and orange
Battery low
Solid
Orange
System error/warning
Table 2: 3G/4G/LTE LED status
Device state
Color
Description
Off
None
3G/4G/LTE off
On
Blue
3G/4G/LTE on
Blinking
Blue
No signal
Table 3: WAN Ethernet LED status
LED
Color
Description
Activity
Off
No activity
Green
Receive
Orange
Transmit
Link
Off
No link
Green
Link
2.3.2 Buttons
Table 4: Power button
Device state
Action
Result
Off
Press and hold for 2 seconds
Turns on
On
Press once
Turns off
Table 5: Factory reset button
Device state
Action
Result
On
Press and hold for 5 seconds
System LED flashes and device goes through reset process
2.3.3 Ports
The device has three ports:
 WAN Gigabit Ethernet
 USB 3.0 (USB 2.0 compatible)
 Micro-SIM slot (accessible by removing bottom cover)
