Intel® Server S2600WT Product Family Configuration Guide and Spares/Accessories List
13
Intel Product Code (iPC):
R1304WTXXX
1U – 4 x 3.5” HDD or 4 x 2.5” SSD front mount drives
Order Code Information:
MM# - 936121
UPC - 00735858287944
EAN - 5032037067492
MOQ - 1
Product Type: Chassis Only
Chassis Form Factor: 1U rack mount
Chassis dimensions: L=712mm, W=439mm, H=43.2mm
Packaged Gross Weight: 19 Kgs, 41.9 Lbs
Un-packaged Net Weight: 10.3 Kgs, 22.7 Lbs
Outer Box Dimensions: L=983mm, W=577mm, H=260mm
Product Definition and Configuration Requirements
Intel product code R1304WTXXX includes the following
components:
(1) – 1U Chassis with Quick Reference Label affixed to top cover
(1) – Air duct
(6) – Dual rotor system fans – iPC FR1UFAN10PW
(1) – Pre-installed Standard Control Panel assembly (board only –
iPC FXXFPANEL)
(1) – Pre-installed Front I/O Panel assembly (1 x VGA and 2 x USB)
(w/internal attach cables)
(1) – SATA Optical drive bay with filler panel
• Includes optical drive mounting latch kit – iPN H19168-00x
• Includes optical drive power cable – iPN G95880-00x
(4) – 3.5” Hot-swap drive bays with drive carriers and drive blanks
• includes (1) 12 Gb SAS backplane – iPC FR1304S3HSBP
• includes (4) 3.5” hot swap drive carriers – iPC
FXX35HSCAR
(1) – Server board to backplane power cable – iPN H38458-00x
(1) – Server board to backplane I2C cable – iPN H39941-00x
(2) – CPU heatsinks – iPC FXXCA84X106HS
(2) – CPU heat sink Mylar Spacer inserts – iPN H28618-00x
(2) – Riser card mounting brackets – (riser cards sold separately. See
chapter 5.7.1)
(1) – Power Supply Bay blank insert
(8) – DIMM slot blanks – iPN H43597-00x
(2) – Chassis handles (1 set) installed – iPN H19171-00x
(2) – AC Power Cord retention strap assembly – iPN H23961-00x
Server board and riser card mounting screws
Spares for each screw type included
Required Items – Sold Separately:
• Intel® Server Board S2600WT (choose one)
o iPC S2600WT2 – with 1G LOM
o iPC S2600WTT – with 10G LOM
• Power supply module(s) – (Choose one type)
two common modules required for
redundancy
o iPC FXX750PCRPS – 750 W AC Power
Supply Module
o iPC AXX750DCCRPS – 750 W DC Power
Supply Module
(Available Late Q2 2015)
• Power Cord(s) – See chapter 5.10
• Rack Mount Kit – See chapter 5.11
• 1 or 2 Intel® Xeon® Processor E5-2600 v3
product family
• ECC DDR4 memory (RDIMM or LRDIMM)
Optional Intel Accessories – Sold Separately:
• iPC F1UL16RISER2 – One x16 PCIe* 3.0 slot
Riser Card – (1 for each riser slot)
• Intel® I/O Module – See chapter 5.8 for options
• Intel® SAS RAID Card / Module – See section
5.9 for options
• SAS/SATA Data cables – Cable selection is
dependant on desired storage option. See
Chapter 4.2.1 for available cable options
• iPC A1UBEZEL – Lockable
front system bezel
• iPC AXXRMM4LITE – Intel® Remote
Management Module Lite key. For advanced
management features
• Storage Drives
See Chapter 5 for all available accessory options.
