Intel® Server S2600WT Product Family Configuration Guide and Spares/Accessories List
67
5.7.2 2U Riser Card Options
Intel Product Code Order Information
Product Description Product Type
iPC – A2UL8RISER2
MM# – 934885
UPC –
00735858288675
EAN –
5032037067959
MOQ – 1
2U 3-slot PCIe* riser card option
Riser Slots #1 & #2 Riser Card Option
Kit includes:
(1) riser card PCBA
PCIe* x8 elec, x16 mechanical
PCIe* x8 elec, x16 mechanical
Slot-3 (Bottom) PCIe* x8 elec, x8 mechanical
• 2U Building Block Accessory Kit
• 2U Spare FRU
Each 3-slot riser card assembly has support for up to two full height full length add-in cards (top and middle slots) and one full height ½ length add-in card (bottom
slot).
Intel Product Code Order Information
Product Description Product Type
iPC – A2UL16RISER2
MM# – 934886
UPC –
00735858288668
EAN –
5032037067942
MOQ – 1
2U 2-slot PCIe* Riser card option
Riser Slots #1 & #2 Riser Card Option
Kit includes:
(1) Riser card PCBA
(1) 12V-AUX Power Cable
Slot-1 (Top) PCIe* x16 elec, x16 mechanical
Slot-2 (Bottom) PCIe* x8 elec, x8 mechanical
• 2U Building Block Accessory Kit
• 2U Spare FRU
* Required Kit for Intel® Xeon Phi™ or
high power PCIe* add-in card support
Each 2-slot riser card assembly has support for one full height full length add-in card (top slot) and one full height ½ length add-in card (bottom slot).
Note: The A2UL16RISER2 accessory kit includes a 12V Auxiliary Power cable which can be used to provide additional 12V power for high power PCIe* add-in cards
that require it.
Note: The x16 2-slot riser card is included in Intel Accessory Kit A2U44X25NVMEDK. Systems configured with the A2U44X25NVMEDK accessory kit cannot support
dual Intel® Xeon Phi™ coprocessor cards or dual non-Intel GPGPU cards.
