Intel® Server S2600WT Product Family Configuration Guide and Spares/Accessories List
62
R2208WT (8x2.5” – 1 drive bay) and R2216WT (16x2.5” – 2 drive bays) system configurations utilize the same front I/O module bay assembly containing the System
Control Panel and Front I/O Panel (as shown in Figure 9). When upgrading a R2208WT based system to an R2216WT based system, all that is needed is the removal
of the Bay #2 face plate to insert the new drive bay, and adding the required data cables. No other chassis changes or additions are required.
Available SAS / SATA 8x25” accessory kits include the following.
Intel Product Code Order Information
Product Description Product Type
iPC – A2U8X25S3HSDK
MM# – 935066
UPC – 00735858288767
EAN – 5032037068048
MOQ – 1
8x2.5” SAS/SATA Front Mount Hot Swap Drive Bay Module for all 2U
2.5” systems
Kit Includes:
(1) Drive Bay Assembly Module
(1) 8x2.5” hot swap backplane
(8) 2.5” drive carriers + drive blanks
(1) 75mm I2C Backplane-to-Backplane jumper cable
(1 set) mounting hardware
Required (Sold Separately):
SAS / SATA Data Cables. See section 4.2.5
• 2U 2.5” Drive
Upgrade Kit
• 2U Building Block
Accessory Kit
Intel Product Code Order Information
Product Description Product Type
iPC – A2U8X25S3DPDK
MM# – 935067
UPC – 00735858288774
EAN – 5032037068055
MOQ – 1
8x2.5” Dual Port SAS Front Mount Hot Swap Drive Bay Module for all
2U 2.5” systems
Kit Includes:
(1) Drive Bay Assembly Module
(1) 8x2.5” hot swap backplane
(8) 2.5” drive carriers + drive blanks
(1) 75mm I2C Backplane-to-Backplane jumper cable
(1 set) mounting hardware
Required (Sold Separately):
SAS / SATA Data Cables. See section 4.2.5
• 2U 2.5” Drive
Upgrade Kit
• 2U Building Block
Accessory Kit
