Intel® Server S2600WT Product Family Configuration Guide and Spares/Accessories List
48
4.3 Intel SAS / SATA Data Cable Kits
Each cable accessory kit referenced in the this section will identify the connector type at each end of the cable using the following identifiers: HR, HD, and MS. The
following table identifies the three cable connector types and their identifiers.
HR = Right Angle SFF-8643 Mini SAS HD Connector
HD = Straight SFF-8643 Mini SAS HD Connector
MS = Straight SFF-8087 Mini SAS Connector (compatible with 6Gb/sec SAS controllers and expanders)
Cable Kit Product Code Decoder
Example – iPC AXXCBL950HDMS
AXXCBL – Identifies an accessory cable kit
950 – identifies the length of the cable
HD – identifies that one cable connector supports an SFF-8643 type connector
MS – identifies that one cable connector supports an SFF-8087 type connector
