v240M – Marine Satellite Communication System
56
Antenna Control Unit
Antenna
RX
Modem Interface
RX
Satellite
Modem
Antenna Control Unit
Antenna
TX
Modem Interface
TX
Satellite
Modem
Antenna and ACU Congurations
Below are diagrams of some common antenna installation congurations.
Figure 68. Basic System Conguration RX: 1 Antenna and 1 Modem
Figure 69. Basic System Conguration TX: 1 Antenna and 1 Modem
