77
OPERATION INSTRUCTION
Antenna Settings
Manual Search
Search for the desired satellite manually.
Antenna movement
Setup mode
Save
Manual search MODE
Antenna MODE
SETUP MODE ?
4
YES NO
1. Press the LEFT arrow key to move the cursor to YES and press the OK key to enter
SETUP mode.
4
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press the OK key to enter the ANTENNA menu.
4
+MANUAL SEARCH +SET POL ANGLE
+SEARCH PARAM +SET PARAMETERS
3. Press the OK key to enter the MANUAL SEARCH menu.
STEP SIZE AZIMUTH ELEVATION AGC
#
00.2 # 231.7 48.3 301 Fn
4. Current IF tracking signal level (AGC) / (SIG) is displayed to assist you in manually peaking
the AZIMUTH (0°-360°) and ELEVATION (0°-90°) angles for the best signal level.
Press the NUMBER key to change the STEP SIZE (Range : 0.1~99.9).
Press the LEFT and RIGHT arrow keys to increase or decrease the azimuth angles. Press the
UP and DOWN arrow keys to increase or decrease the elevation angles. Press the FUNCTION
key to save the current settings or abort and return to the main display.
SAVE CURRENT SAT INFO?
4
YES NO
5. If the current settings are able to locate the satellite, press the FUNCTION key to save
“current satellite information”. This will help to reduce the satellite acquisition time after
restarting the system. Press the LEFT arrow key to move cursor to YES and press the OK key
to save the settings.
NOTE: If the gyrocompass type is not NMEA or the gyrocompass is not connected to the ACU,
the information cannot be saved.
