v240M – Marine Satellite Communication System

Setup Antenna LNB pol Angle

LNB pol angle type

Setup mode

Set pol angle MODE

Antenna MODE

LNB pol angle Signal

SETUP MODE ?

YES NO

1. Press the LEFT arrow key to move the cursor to YES and press the OK key to enter SETUP

mode.

+ANTENNA +SATELLITE

+SYSTEM +INSTALLATION

2. Press the OK key to enter the ANTENNA menu.

+MANUAL SEARCH

+SET POL ANGLE

+SEARCH PARAM +SET PARAMETERS

3. Press the RIGHT arrow key to move cursor to the SET POL ANGLE menu and press the

OK key to enter it.

4. Press the UP and DOWN arrow keys to select the LNB pol angle menu and press the OK

key to run the selected operation ‘ CALIBRATION ‘ or ‘ MANUAL ADJUST‘.

Select MANUAL ADJUST to control the LNB pol angle manually. If the control board, skew

potentiometer or belt is replaced, select CALIBRATION to calibrate the LNB pol angle.

5. Press the UP and DOWN arrow keys to increase or decrease the LNB pol angle manually

and the correspondent SIGNAL level will be displayed next to it.

If the tracking satellite is a C-band satellite, the POLARITY item is shown as above.

If the tracking satellite is a Ku-band satellite, the POLARITY item is not shown.

Polarity is changeable to “LINEAR”, “RHCP”, and “LHCP” with the LEFT/RIGHT key.

Press the BACK key to return to the main display.

NOTE: LNB POL ANGLE menu will be displayed only if MANUAL ADJUST is selected.

SELECT L NB POL.ANGLE M ENU

CALIBRATION

LNB POL ANGLE POLARITY SIGNAL:180

10.0 LINEAR

LNB POL ANGLE SIGNAL:180

20.5
