Intellian v240M - System Configuration

11
INTRODUCTION
For detailed information regarding system congurations, please see section 2.
ACU and Antenna Congurations are in Chapter 4.
Figure 1. Basic System Conguration: Single Antenna and Single Modem
System Conguration
For your VSAT system to work properly, the system will have to be connected with
all of the provided components properly, as shown in the gures below (Refer to the
next chapter ‘Installation’ in this manual for more detailed connection instructions).
Separate purchase of a satellite modem and other network equipment is required.
Basic System
Conguration
Antenna Control Unit
TX
RXTX
Modem Interface
Antenna Power 100~240V AC
Air Conditioner Power 220V AC
RX
Satellite
Modem
Ship’s Gyrocompass
(Not supplied)
