ACU INSTALLATION
Selection of Installation Site
The ACU should be installed below deck, in a location that is:
– Dry, cool, and ventilated.
– Allows easy access.
ACU Dimensions
Dimension of ACU
43.1 cm (17")
47.5 cm (18.7")
20.0 cm (7.9")
45.5 cm (17.9")
13.0 cm (5.1")
48.5 cm (19.1")
46.6 cm (18.4")
3.2 cm (1.3")
4.4 cm (1.7")
38 cm (15")
Figure 67. ACU Dimensions
