Intellian v240M User Manual

v240M – Marine Satellite Communication System
96
Setting local
System Settings
System MODE
Set local frequency MODE
LNB info
Setup mode
Save
SETUP MODE ?
4
YES NO
1. Press the LEFT arrow key to move cursor to YES and press the OK key to enter SETUP
mode.
+ANTENNA +SATELLITE
4
+SYSTEM +INSTALLATION
2. Press the DOWN arrow key to move cursor to SYSTEM and press the OK key to enter it.
4
+SET LOCAL +SET LOCATION
+MODEM PORT +MANAGEMENT
3. Press the OK key to enter the SET LOCAL menu to set the LNB local frequency.
4
13V + 0KHz 18V + 0KHz
+ 10000MHz 11300MHz
13V + 22KHz 18V + 22KHz
+ 10750MHz 09750MHz
4. Set the LNB local oscillator frequency for each correspondent voltage power.
(13V+0KHz , 18V+0KHz, 13V+22KHz, 18V+22KHz)
The local frequency of C-band is xed as 5150MHz.
Press the BACK key and press the LEFT and RIGHT arrow keys to select the parameter you
wish to edit. Press the OK key to edit parameter. Or press the BACK key again to return
to the main display.
LNB LOCAL: the selectable LNB frequencies are depending on the installed LNB type.
SAVE ?
4
YES NO
5. Press the LEFT arrow key to move cursor to YES and press the OK key to save the current
settings. Or move the cursor to NO and press the OK key to abort and return to the main
display.
