OPERATION INSTRUCTION
Setting Location
System MODE
Set location MODE
Gyrocompass type
and Baud rate
Setup mode
SETUP MODE ?
4
YES NO
1. Press the LEFT arrow key to move the cursor to YES and press the OK key to enter SETUP
mode.
+ANTENNA +SATELLITE
4
+SYSTEM +INSTALLATION
2. Press the DOWN arrow key to move the cursor to SYSTEM and press the OK key to enter it.
+SET LOCAL
4
+SET LOCATION
+MODEM PORT +MANAGEMENT
3. Press the RIGHT arrow key to move the cursor to SET LOCATION and press the OK key
to enter it.
GYRO TYPE BAUD RATE
NMEA
4800
4. Set the ship’s GYRO TYPE* and BAUD RATE
A search pattern 1 or 3 will initiate according to which GYRO TYPE is selected and the
existence of the gyrocompass input. Set the BAUD RATE as 4800, 9600, 19200 or 38400
according to your device.
A search pattern 1 will initiate automatically if the gyrocompass input does not exist and the
gyrocompass type is to any setting other than GROUND TEST.
NOTE: The bow offset will not be saved automatically if a Search 1 pattern is initiated. In this case,
the antenna will need to retarget the desired satellite using Search 1 every time if the antenna restarts.
Gyrocompass
search type
Setting of Heading Device
Existence of Heading Data No Device
NMEA
NMEA 2000
Ground Test
With Heading Data
Search 1 Search 3 Search 3
Without Heading Data
Search 1 Search 1 Search 3
GYRO TYPE*
• NO DEVICE
• NMEA
• NMEA 2000
• GROUND TEST
