OPERATION INSTRUCTION
Search 3 range
Search 1 range
Search Parameters
Setup mode
Manual search MODE
Antenna MODE
Search param
SETUP MODE ?
4
YES NO
1. Press the LEFT arrow key to move the cursor to YES and press the OK key to enter
SETUP mode.
4
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press the OK key to enter the ANTENNA menu.
+MANUAL SEARCH + SET POL ANGLE
4
+SEARCH PARAM +SET PARAMETERS
3. Press the DOWN arrow keys to move the cursor to SEARH PARAM and press the OK key
to select it.
SEARCH WAIT TIME INCREMENT STEP
030 0.50
4. Set the SEARCH WAIT TIME and INCREMENT STEP
Set the time-out for automatic initiation of a search after the signal level drops below the
predened threshold value (Range : 1 - 120 sec)and set the increment step size (Range :
0.01 – 5.00 sec).
SEARCH1 AZ SEARCH1 EL
400 06
SEARCH3 AZ SEARCH3 EL
003 04
5. Set the SEARCH 1 and 3 AZ (Azimuth) range and EL (Elevation) range.
SEARCH 2 is reserved for future use.
