Intercomp CW250 - Continuous Mode; Continuous Data Format

CW250, Users
Rev M, April 2018
Page 13 of 31
Continuous
When the Continuous mode has been selected, the scale automatically and
continuously outputs the weight approximately one time per second.
Data Format
When the serial output is set to either on-demand or continuous mode, the transmitted
data is in the format shown as: AAAAAAA BB<cr><lf>
Item
Definition
ASCII Hex
ASCII Decimal
AAAAAAA
weight
BB
units “lb” or “kg”
<cr>
carriage return
0D
13
<lf>
linefeed
0A
10
The AAAAAAA field will vary in length depending on the length of the number and may
contain a decimal point and/or a minus sign. The weight will either be local weight or
total weight, depending on which mode is selected.
Accumulating Print
Refer to the "Using Accumulated Total" section for specific information about the
"Accumulating Print Axle" and "Accumulating Print Standard" communication modes.
