CW250, Users
Rev M, April 2018
Page 14 of 31
Accumulated Total
The CW250 scale platform can be used separately, in pairs, or in groups to measure a
support load or a total weight across the scales connected to the system in one
weighing procedure. The Accumulated Total feature "accumulates" the weights as each
individual load is weighed.
To use the Accumulated Total feature, each scale in the system must be numbered
correctly. The scale selected to print from or to display the accumulated total must have
the print mode set to either the "Accumulating Print Axle" or "Accumulating Print
Standard" mode.
Accumulating Print Axle
If the "Accumulating Print Axle" mode has been selected for the designated scale,
press the PRINT/ACCUMULATE button to add the current total weight to the
accumulated total weight. If the scale designated as the "Accumulating Print Axle"
mode scale is connected to a printer, a print ticket will be printed. The print ticket format
is in reference to the individual wheels and axles of the vehicle being weighed or is
formatted in a standard weight accumulation mode.
The following example shows a 4-scale system with two separate weighings having
been conducted and accumulated.
Subgroup #1: "WHL 1" is scale number 1 and "WHL 2" is the second scale. "AXL 1"
shows the total weight of scale number one and two. "AXL2" shows the weights from
scale number three and four. Both the subtotal and accum total weights reflect the
Subgroup #1 totals
Subgroup #2": WHL 1" is scale number 1 and "WHL 2" is the second scale. "AXL 1"
shows the total weight of scale number one and two. "AXL2" shows the weights from
scale number three and four. The subtotal grp 2 weight reflects the total weight for the
subgroup #2. The accum total weight reflects the Subgroup #1 total and Subgroup #2
total.
PRINT / ACCUMULATE
button has been pressed
PRINT / ACCUMULATE
button has been pressed
