Serial Output Setup
The CW250 scale can be set to one of four different serial output modes.
1. On-Demand
2. Continuous
3. "Accumulating Print" Wheel Axle
4. "Accumulating Print" Standard
Serial Output Mode Setup
To access Serial Output Mode Setup, press the PRINT/ACCUMULATE and ZERO
buttons simultaneously until the message "." is displayed. Press the PRINT/
ACCUMULATE button to scroll through the Menu until the display shows "". Press
the PRINT/ACCUMULATE button one time to display the setting number. Set the print
mode to the number of the Communication Mode setting (shown below) required by
using the LOCAL/TOTAL button to increment and the ZERO button decrement the
number.
Accumulating Print Standard
For the best result, select only one scale to be designated for Communication
Mode 1, 2 or 3. The scale being used to print should be the scale selected as
the Communication Mode designation. The default setting is"0".
Press the PRINT/ACCUMULATE button. The display screen will show "". Press
the PRINT/ACCUMULATE button to change the baud rate setting. Press the LOCAL/
TOTAL or the ZERO button to cycle through the available baud rates (1200, 2400,
4800, 9600, 19200, 38400, 57600 and 115200). When the desired baud rate is
entered, press the PRINT/ACCUMULATE button. The baud rate should only be set on
the scale connected to the printer. Press the PRINT/ACCUMLATE button to save the
baud rate setting and advance the menu. The scale can now be turned off to exit the
Mode Menu.
On-Demand
When the scale is set in the On-Demand mode, the weight is transmitted each time the
PRINT/ACCUMULATE button is pressed. Press PRINT/ACCUMULATE button to print
either the local or total weight (depending on the local/total setting of the scale). The
On-Demand setting is the default print mode.
