Totalizing Setup
The CW250 scale must be setup correctly in order to communicate with other scales in
the system. If the system is not setup correctly, an "error icon" and message “ “will
be displayed when attempting to view the total weight.
1. To begin Totalizing Setup, press the LOCAL/TOTAL and ZERO buttons
simultaneously.
2. The message "" will be displayed. Press the PRINT/ACCUMULATE button.
A number will be displayed followed by 3 dashes. The number displayed is the
scale number. Use the LOCAL/TOTAL button to increment and the ZERO button
decrement the number. When the desired number is displayed, press the
PRINT/ACCUMULATE button.
3. The message "" will be displayed. Press the PRINT/ACCUMULATE button.
The display will show three dashes followed by a number. The number
represents the total number of scales in the system. Use the LOCAL/TOTAL
button to increment and the ZERO button to decrement the number. When the
desired number is displayed, press the PRINT/ACCUMULATE button. NOTE:
The maximum number of scales in a system is 32.
4. If the scale number is "1", the display will issue a prompt confirming the scale
designation is "". Press the PRINT/ACCUMULATE button. Use the
LOCAL/TOTAL or the ZERO button to toggle either "" or "". A scale with a
HOST designation controls the entire scale network. The setting should be set to
"yes" if the scale network consists of scales only. If the system uses an external
device such as a PDA or PC to view the weights, the display setting should be
set to "no" because the external host device controls the scale network. Press
the PRINT/ACCUMULATE button to save the setting.
SETUP EXAMPLE: Setup for two scales. First Scale: Enter "01" for the first scale
number. Enter "02" for the total number of scales. Enter "yes" for the "Host"
setting. Second Scale: Enter "02" to identify the second scale and "02" for the
total number of scales.
Total # of Scales
(Displayed on scale #1 only)
