Intergas Xtend-HB-CUSP05 - Scope of Delivery

12


R32 Field charge label
R32 weight (kg)
Factory charge
Additional charge
Total charge
 SCOPE OF DELIVERY
1
2
3
4 5 6
1
Indoor unit
7
Insulation material (for refrigerant lines indoor unit)
2
Outdoor unit
8
Field charge sticker
3
Low loss header
9
Plug-in connectors (5 pole for X13 and 6 pole X2)
4
Indoor unit wall hanging bracket
10
Installation- and user manuals
5
Flare nut 1/4" (refrigerant liquid line)
11
Warranty card
6
Compression nut and 22mm olive (2x)
7 8
9
10 11
