1.1.3 Symbols on the packaging
1.1.4 Abbreviations
INSTRUCTIONS (THIS SIDE UP)
The arrow is pointing up to indicate that the
contents must be transported and stored upright.
INSTRUCTIONS (FRAGILE)
This symbol indicates that the contents of the box
are fragile. Handle the contents carefully.
► CH: Central heating
► DHW: Domestic hot water
► IDU: Indoor unit
► ODU: Outdoor unit
► WDC: Weather-dependent control
INSTRUCTIONS (KEEP DRY)
This symbol indicates that the contents of the box
must be kept dry.
INSTRUCTIONS (MAXIMUM STACKING HEIGHT)
This symbol indicates how many of these boxes
can be stacked.
INSTRUCTIONS (NO STANDING)
This symbol indicates that you cannot stand on the
contents of the box.
INSTRUCTIONS (DO NOT USE HOOKS)
This symbol indicates that a hook cannot be used
to hoist the product.
INSTRUCTIONS (NO TILTING)
This symbol indicates that the contents of the box
cannot be tilted.
INSTRUCTIONS (DO NOT STACK ON SIDE)
This symbol indicates that the product cannot be
stacked on its side.
REFRIGERANT TYPE (R)
R32 is an A2L refrigerant, which has low
flammability and low toxicity.
1.1.5 Information about the text
► The dimentions within the installation instructions are in
millimetres unless otherwise specified.
