In this example, the heat pump blocker time program is set by using
a time period (00:00 to 06:00). During this time period, the heat pump
will be deactivated. All demands for heat will then be forwarded to
the boiler.
The heat pump blocker program always requires an ‘On’ and ‘O’
time period.
1. Go to ‘Settings‘ on the Wi-Fi control screen.
2. Select ‘edit programs’.
3. Select ‘Heat pump blocker’.
4. Edit a time period by clicking on the ‘edit’ icon , or add a time.
5. Select a time. Use the arrows to set the desired time (e.g. 00:00).
6. Select an action (‘On’).
7. Click on ‘change’.
8. Select a second time period.
9. Select a time. Use the arrows to set the desired time (e.g. 06:00).
10. Select an action (‘O’).
11. Click on ‘Close’ to leave the program.
12. The settings have been saved.
Using a separate day program (independent of Silent mode), the
heat pump can be blocked for a period of time. Using P128, this
timed program can be activated or deactivated:
‘0’ = Timed program o; heat pump not blocked
‘1’ = Timed program on; heat pump blocked
.
Setting the heat pump blockage:
Setting Silent mode:
In this example, Silent mode is set by using a time period
From 23:00 to 07:00. During this time period, the noise level of the
outdoor unit will be reduced. Silent mode always requires an ‘On’
and ‘O’ time period.
1. Go to ‘Settings‘ on the Wi-Fi control screen.
2. Select ‘edit programs’.
3. Select ‘ Silent mode’.
4. Edit a time period by clicking on the ‘edit’ icon , or add a time.
5. Select a time. Use the arrows to set the desired time (e.g. 23:00).
6. Select an action (‘On’).
7. Click on ‘change’.
8. Select a second time period.
9. Select a time. Use the arrows to set the desired time (e.g. 07:00).
10. Select an action (‘O’).
11. Click on ‘Close’ to leave the program.
12. The settings have been saved.
Heat pump blockage Mode
