Interlogix NS3552-8P-2S-V2 User Manual

Chapter 4: Web configuration
116 NS3552-8P-2S-V2 User Manual
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
• Click Refresh to refresh the page immediately.
• Click I<< to update the table starting from the first entry in the VLAN Table (i.e., the
entry with the lowest VLAN ID).
• Click >> to update the table, starting with the entry after the last entry currently
displayed.
VLAN membership status
The VLAN Membership Status for Combined users page provides an overview of
membership status for VLAN users.
The page includes the following fields:
Object Description
VLAN ID Indicates the ID of this particular VLAN.
Port Members The VLAN Membership Status Page shows the current VLAN port
members for all VLANs configured by a selected VLAN User
(selection shall be allowed by a Combo Box). When ALL VLAN Users
is selected, it shall show this information for all the VLAN Users, and
this is the default. VLAN membership allows the frames classified to
the VLAN ID to be forwarded to the respective VLAN member ports.
VLAN User A VLAN User is a module that uses services of the VLAN
management functionality to configure VLAN memberships and
VLAN port configuration such as PVID and UVID. Currently we
support following VLAN s:
CLI/Web/SNMP: This is referred as static.
NAS: NAS provides port-based authentication, which involves
communications between a Supplicant, Authenticator, and an
