Chapter 4: Web configuration
NS3552-8P-2S-V2 User Manual 81
UDLD port status
The page includes the following fields:
Object Description
UDLD Admin State The current port state of the logical port, Enabled if any of
state(Normal,Aggressive) is Enabled.
Device ID (Local) The ID of Device.
Device Name (Local) Name of the Device.
Bidirectional State The current state of the port.
Neighbor status
The page includes the following fields:
Object Description
Port The current port of the neighbor device.
Device ID The current ID of the neighbor device.
Link Status The current link status of the neighbor port.
Device Name Name of the neighbor device.
Buttons
• Select the Auto-refresh check box to refresh the page automatically. Automatic
refresh occurs every three seconds.
• Click Refresh to refresh the page immediately.
Simple Network Management Protocol (SNMP)
SNMP overview
The Simple Network Management Protocol (SNMP) is an application layer protocol that
facilitates the exchange of management information between network devices. It is part
of the Transmission Control Protocol/Internet Protocol (TCP/IP) protocol suite. SNMP
permits network administrators to manage network performance, find and solve network
problems, and plan for network growth.
An SNMP-managed network consists of the following:
• Network management stations (NMSs): Sometimes called consoles, these
devices execute management applications that monitor and control network
elements. Physically, NMSs are usually engineering workstation-caliber computers
with fast CPUs, megapixel color displays, substantial memory, and abundant disk
space. At least one NMS must be present in each managed environment.
