Chapter 4: Web configuration
NS3552-8P-2S-V2 User Manual 91
Buttons
• Click Add New Entry to add a new access entry.
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
Port management
Use the Port menu to display or configure the industrial managed switch ports. This
section has the following items:
Port Configuration Configures port connection settings
Port Statistics Overview Lists Ethernet and RMON port statistics
Port Statistics Detail Lists Ethernet and RMON port statistics
SFP Module Information Displays SFP information
Port Mirror Sets the source and target ports for mirroring
Port configuration
Ports can be configured on the Port Configuration page.
The page includes the following fields:
Object Description
Port This is the logical port number for this row.
Port Description Indicates the per port description.
Link The current link state is displayed graphically. Green indicates the
link is up and red is down.
