Interlogix NS3552-8P-2S-V2 User Manual

Chapter 4: Web configuration
NS3552-8P-2S-V2 User Manual 79
Object Description
RX and TX Lease Query The number of lease query (option 53 with value 10) packets
received and transmitted.
RX and TX Lease
Unassigned
The number of lease unassigned (option 53 with value 11) packets
received and transmitted.
RX and TX Lease Unknown The number of lease unknown (option 53 with value 12) packets
received and transmitted.
RX and TX lease Active The number of lease active (option 53 with value 13) packets
received and transmitted.
RX Discarded Checksum
Error
The number of discarded packets where IP/UDP checksum is in
error.
RX Discarded from
Untrused
The number of discarded packets that are coming from an untrusted
port.
Buttons
• Select the Auto-refresh check box to refresh the page automatically. Automatic
refresh occurs every three seconds.
• Click Refresh to refresh the page immediately.
• Click Clear to clear the counters for the selected port.
UDLD
The UDLD Port Configuration page permits the user to inspect and change the current
Unidirectional Link Detection (UDLD) configurations.
