Interlogix NS3552-8P-2S-V2 User Manual

Chapter 4: Web configuration
78 NS3552-8P-2S-V2 User Manual
Buttons
• Select the Auto-refresh check box to refresh the page automatically. Automatic
refresh occurs every three seconds.
• Click Refresh to refresh the page immediately.
Detailed statistics
The DHCP Detailed Statistics page provides statistics for DHCP snooping. Note that
the normal forward per-port TX statistics are not increased if the incoming DHCP
packet is done by a L3 forwarding mechanism. Clearing the statistics on a specific port
may not affect global statistics since it gathers a different layer overview.
The page includes the following fields:
Object Description
RX and TX Discover The number of discover (option 53 with value 1) packets received and
transmitted.
RX and TX Offer The number of offer (option 53 with value 2) packets received and
transmitted.
RX and TX request The number of request (option 53 with value 3) packets received and
transmitted.
RX and TX Decline The number of decline (option 53 with value 4) packets received and
transmitted.
RX and TX ACK The number of ACK (option 53 with value 5) packets received and
transmitted.
RX amd TX NAK The number of NAK (option 53 with value 6) packets received and
transmitted.
RX and TX Release The number of release (option 53 with value 7) packets received and
transmitted.
RX and TX Inform The number of inform (option 53 with value 8) packets received and
transmitted.
