Chapter 4: Web configuration
144 NS3552-8P-2S-V2 User Manual
The page includes the following fields:
Object Description
MSTI The bridge instance. The CIST is the default instance, which is
always active.
Priority Controls the bridge priority. Lower numerical values have higher
priority. The bridge priority plus the MSTI instance number,
concatenated with the 6-byte MAC address of the switch, forms a
bridge identifier.
Buttons
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
MSTI configuration
The MSTI Configuration page permits the user to inspect and change the current STP
MSTI bridge instance priority configurations.
