Interlogix NS3552-8P-2S-V2 User Manual

Chapter 4: Web configuration
NS3552-8P-2S-V2 User Manual 159
The page includes the following fields:
Object Description
VLAN ID The VLAN ID of the entry.
Querier Version The current working querier version.
Host Version The current working host version.
Querier Status Shows whether the querier status is "ACTIVE" or "IDLE".
Querier Transmitted The number of transmitted queries.
Querier Received The number of received queries.
V1 Reports Received The number of received V1 reports.
V2 Reports Received The number of received V2 reports.
V3 Reports Received The number of received V3 reports.
V2 Leaves Received The number of received V2 leaves.
Router Port Displays the ports that are acting as router ports.
Port Switch port number.
Status Indicates whether or not the specific port is a router port.
Buttons
• Click Refresh to refresh the page immediately.
• Click Clear to clear all statistics counters.
• Select Auto-refresh to automatically refresh the page every three seconds.
IGMP group information
Entries in the IGMP group table are shown in the IGMP Snooping Group Information
page. The IGMP group table is sorted first by VLAN ID, and then by group.
Each page shows up to 99 entries from the IGMP group table (default is 20 entries per
page). The range of entries per page can be typed into the Start from VLAN and
entries per page fields. When initially accessing the page, it shows the first 20 entries
from the beginning of the IGMP Group table. The Start from VLAN and group
Address fields permit the user to select the starting point in the IGMP group table.
