Interlogix NS3552-8P-2S-V2 User Manual

Chapter 4: Web configuration
NS3552-8P-2S-V2 User Manual 165
The page includes the following fields:
Object Description
Delete Select this check box to delete the entry. The designated entry will be
deleted during the next save.
Port The logical port for the settings.
Filtering Group The IP Multicast Group that will be filtered.
Buttons
• Click Add New Filtering Group to add a new entry to the Group Filtering table.
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
MLD snooping status
The MLD Snooping Status page provides MLD snooping status.

Interlogix NS3552-8P-2S-V2 Specifications

General

Brand	Interlogix
Model	NS3552-8P-2S-V2
Category	Switch
Language	English
