Chapter 4: Web configuration
NS3552-8P-2S-V2 User Manual 201
MAC parameters
Object Description
SMAC Filter This is only shown when the frame type is Ethernet Type or ARP.
Specify the source MAC filter for this ACE.
Any: No SMAC filter is specified (SMAC filter status is "don't-care”).
Specific: If you want to filter a specific source MAC address with this ACE,
choose this value. A field for entering an SMAC value appears.
SMAC Value When Specific is selected for the SMAC filter, you can enter a specific
source MAC address. The legal format is "xx-xx-xx-xx-xx-xx" or
"xx.xx.xx.xx.xx.xx" or "xxxxxxxxxxxx" (x is a hexadecimal digit). A frame that
hits this ACE matches this SMAC value.
DMAC Filter Specify the destination MAC filter for this ACE.
Any: No DMAC filter is specified. (DMAC filter status is "don't-care”).
MC: Frame must be multicast.
BC: Frame must be broadcast.
UC: Frame must be unicast.
Specific: If you want to filter a specific destination MAC address with this
ACE, choose this value. A field for entering a DMAC value appears.
DMAC Value When Specific is selected for the DMAC filter, you can enter a specific
destination MAC address. The legal format is "xx-xx-xx-xx-xx-xx" or
"xx.xx.xx.xx.xx.xx" or "xxxxxxxxxxxx" (x is a hexadecimal digit). A frame that
hits this ACE matches this DMAC value.
VLAN parameters
Object Description
802.1Q Tagged Specify whether frames can hit the action according to the 802.1Q tagged.
Selections include:
Any: Any value is allowed ("don't-care").
Enabled: Tagged frame only.
Disabled: Untagged frame only.
The default value is Any.
VLAN ID Filter Specify the VLAN ID filter for this ACE.
Any: No VLAN ID filter is specified. (VLAN ID filter status is "don't-care”).
Specific: If you want to filter a specific VLAN ID with this ACE, choose this
value. A field for entering a VLAN ID number appears.
VLAN ID When Specific is selected for the VLAN ID filter, you can enter a specific
VLAN ID number. The allowed range is 1 to 4095. A frame that hits this ACE
matches this VLAN ID value.
Tag Priority Specify the tag priority for this ACE. A frame that hits this ACE matches this
tag priority. The allowed number range is 0 to 7. The value Any means that
no tag priority is specified (tag priority is "don't-care”).
ARP parameters
Object Description
ARP/RARP Specify the available ARP/RARP opcode (OP) flag for this ACE.
