Interlogix NS3552-8P-2S-V2 User Manual

Chapter 4: Web configuration
204 NS3552-8P-2S-V2 User Manual
Object Description
IP Option Specify the options flag setting for this ACE.
No: IPv4 frames where the options flag is set must not be able to match this
entry.
Yes: IPv4 frames where the options flag is set must be able to match this
entry.
Any: Any value is allowed ("don't-care”).
SIP Filter Specify the source IP filter for this ACE.
Any: No source IP filter is specified. (Source IP filter is "don't-care”).
Host: Source IP filter is set to Host. Specify the source IP address in the SIP
Address field that appears.
Network: Source IP filter is set to Network. Specify the source IP address
and source IP mask in the SIP Address and SIP Mask fields that appear.
SIP Address When Host or Network is selected for the source IP filter, you can enter a
specific SIP address in dotted decimal notation.
SIP Mask When Network is selected for the source IP filter, you can enter a specific
SIP mask in dotted decimal notation.
DIP Filter Specify the destination IP filter for this ACE.
Any: No destination IP filter is specified. (Destination IP filter is "don't-care”).
Host: Destination IP filter is set to Host. Specify the destination IP address
in the DIP Address field that appears.
Network: Destination IP filter is set to Network. Specify the destination IP
address and destination IP mask in the DIP Address and DIP Mask fields
that appear.
DIP Address When Host or Network is selected for the destination IP filter, you can enter
a specific DIP address in dotted decimal notation.
DIP Mask When Network is selected for the destination IP filter, you can enter a
specific DIP mask in dotted decimal notation.
ICMP parameters
Object Description
ICMP Type Filter Specify the ICMP filter for this ACE.
Any: No ICMP filter is specified (ICMP filter status is "don't-care”).
Specific: To filter a specific ICMP filter with this ACE, you can enter a
specific ICMP value. A field for entering an ICMP value appears.
ICMP Type Value When Specific is selected for the ICMP filter, you can enter a specific ICMP
value. The allowed range is 0 to 255. A frame that hits this ACE matches this
ICMP value.
ICMP Code Filter Specify the ICMP code filter for this ACE.
Any: No ICMP code filter is specified (ICMP code filter status is "don't-care”).
Specific: To filter a specific ICMP code filter with this ACE, you can enter a
specific ICMP code value. A field for entering an ICMP code value appears.
ICMP Code Value When Specific is selected for the ICMP code filter, you can enter a specific
ICMP code value.
The allowed range is 0 to 255. A frame that hits this ACE matches this ICMP
code value.
