Interlogix NS3552-8P-2S-V2 User Manual

Chapter 4: Web configuration
222 NS3552-8P-2S-V2 User Manual
Object Description
Reinitialize: Forces a reinitialization of the clients on the port and thereby a
reauthentication immediately. The clients transfer to the unauthorized state
while the reauthentication is in progress.
Buttons
• Click Refresh to refresh the page.
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
Network access overview
The Network Access Overview page provides an overview of the current NAS port
states for the selected switch.
The page includes the following fields:
Object Description
Port The switch port number. Click to navigate to detailed NAS statistics.
Admin State The port's current administrative state. Refer to NAS Admin State for a
description of possible values.
Port State The current state of the port. Refer to NAS Port State for a description of the
individual states.
Last Source The source MAC address carried in the most recently received EAPOL
frame for EAPOL-based authentication, and the most recently received
frame from a new client for MAC-based authentication.
Last ID The user name (supplicant identity) carried in the most recently received
Response Identity EAPOL frame for EAPOL-based authentication, and the
source MAC address from the most recently received frame from a new
client for MAC-based authentication.
QoS Class QoS Class assigned to the port by the RADIUS server if enabled.
