Chapter 4: Web configuration
NS3552-8P-2S-V2 User Manual 261
Object Description
learning mode, otherwise the management link is lost and
can only be restored by using another non-secure port or by
connecting to the switch via the serial interface.
Static MAC table configuration
The static entries in the MAC table are shown in this table. The static MAC table can
contain 64 entries. The MAC table is sorted first by VLAN ID and then by MAC address.
Object Description
Delete Select to delete the entry. It will be deleted during the next
save.
VLAN ID The VLAN ID of the entry.
MAC Address The MAC address of the entry.
Port Members Checkmarks indicate which ports are members of the entry.
Select or deselect as needed to modify the entry.
Adding a New Static Entry Click Add New Static Entry to add a new entry to the static
MAC table. Specify the VLAN ID, MAC address, and port
members for the new entry. Click Save.
Buttons
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
MAC address table status
Dynamic MAC table
Entries in the MAC table are shown on this page. The MAC table contains up to 8192
entries and is sorted first by VLAN ID, then by MAC address.
