Interlogix NS3552-8P-2S-V2 User Manual

Chapter 4: Web configuration
276 NS3552-8P-2S-V2 User Manual
Object Description
Auto-negotiation
capabilities
Auto-negotiation Capabilities shows the link partner’s MAC/PHY
capabilities.
Buttons
• Click Auto-refresh to refresh the page automatically. Automatic refresh occurs
every three seconds.
• Click Refresh to refresh the page immediately.
Neighbor
The LLDP Neighbor Information page provides a status overview for all LLDP
neighbors. The displayed table contains a row for each port on which an LLDP
neighbor is detected.
The page includes the following fields:
Object Description
Local Port The port on which the LLDP frame was received.
Chassis ID The identification of the neighbor's LLDP frames.
Port ID The identification of the neighbor port.
Port Description The port description advertised by the neighbor unit.
System Name The name advertised by the neighbor unit.
System Capabilities System Capabilities describes the neighbor unit's capabilities. The possible
capabilities are:
1. Other
2. Repeater
3. Bridge
4. WLAN Access Point
5. Router
6. Telephone
7. DOCSIS cable device
8. Station only
9. Reserved
When a capability is enabled, the capability is followed by (+). If the
capability is disabled, the capability is followed by (-).
Management
Address
The neighbor unit's address that is used for higher layer entities to assist the
discovery by the network management. This could, for instance, hold the
neighbor's IP address.
