Interlogix NS3552-8P-2S-V2 User Manual

Chapter 4: Web configuration
NS3552-8P-2S-V2 User Manual 279
• Remote IP Ping
• Cable Diagnostics
Ping
The ICMP Ping page allows you to issue ICMP ping packets to troubleshoot IP
connectivity issues.
After clicking Start, five ICMP packets are transmitted, and the sequence number and
roundtrip time are displayed upon reception of a reply. The page refreshes
automatically until responses to all packets are received, or until a timeout occurs.
The page includes the following fields:
Object Description
IP Address The destination IP Address.
Ping Length The payload size of the ICMP packet. Values range from 2 bytes to 1452
bytes.
Note: Be sure the target IP address is within the same network subnet of the industrial
managed switch, otherwise the correct gateway IP address must be set up.
Buttons
• Click Start to transmit ICMP packets.
• Click New Ping to re-start diagnostics with ping.
IPv6 ping
The ICMPv6 Ping page allows you to issue ICMPv6 ping packets to troubleshoot IPv6
connectivity issues. After clicking Start, five ICMPv6 packets are transmitted, and the
sequence number and roundtrip time are displayed upon reception of a reply. The page
refreshes automatically until responses to all packets are received, or until a timeout
occurs.
