Chapter 4: Web configuration
312 NS3552-8P-2S-V2 User Manual
Class
Usage Range of maximum power used by the PD Class Description
0 Default
12.95 W (or to 15.4 W for AF mode)
25.5 W (or to 30.8 W for AT mode)
Mid power or high power
1 Optional 0.44 to 3.84 W Very low power
2 Optional 3.84 to 6.49 W Low power
3 Optional 6.49 to 12.95 W (or to 15.4 W) Mid power
4 Optional 12.95 to 25.50 W (or to 30.8 W) High power
Port configuration
Inspect and configure the current PoE port settings on the PoE Ethernet Configuration
page.
The page includes the following fields:
Object Description
PoE Mode There are three PoE modes:
Enable: Enables the PoE function.
Disable: Disables the PoE function
Schedule: Enables the PoE function in schedule mode
Schedule Indicates the schedule profile mode. Possible profiles are:
Profile1
Profile2
Profile3
Profile4
AF/AT Mode Permits the user to select 802.3at or 802.3af compatibility
mode. The default vaule is 802.3at mode.
