Interlogix NS3552-8P-2S-V2 User Manual

Chapter 2: Installation
30 NS3552-8P-2S-V2 User Manual
Port Type
Cable Type Connector
10
BASE-T Cat3, 4, 5, 2-pair RJ45
100
BASE-TX Cat5 UTP, 2-pair RJ45
100
0BASE-T Cat5/5e/6 UTP, 2-pair RJ45
100BASE
-FX
50/125 µm or 62.5/125 µm multi-mode 9/125 µm single-
mode
LC (multi/single mode)
1000BASE
-SX/LX
50/125 µm or 62.5/125 µm multi-mode 9/125 µm single-
mode
LC (multi/single mode)
Ethernet devices like hubs and PCs can connect to the industrial managed switch by
using straight-through wires. The two 10/100/1000Mbps ports are auto-MDI/MDI-X and
can be used on straight-through or crossover cable.
Installing the SFP/SFP+ transceiver
SFP transceivers are hot-pluggable and hot-swappable. They can be plugged in and
removed to/from any SFP port without having to power down the industrial managed
switch (see below).
Approved Interlogix SFP transceivers
The industrial managed switch supports both single mode and multi-mode SFP
transceivers. The following list of approved Interlogix SFP transceivers is valid as of the
time of publication:
