Interlogix NS3552-8P-2S-V2 User Manual

Chapter 2: Installation
32 NS3552-8P-2S-V2 User Manual
Part #
Fiber
Connector
# of
Fibers
Fiber
Type
Max
Distance
Wave
Length
Optical
Budget
(dBm)
Optical
Power
(dBm)
Receiver
Sensitivity
(dBm)
Operating
Temperature
S35-2SLC-
30
LC 2
Single
Mode
30 km
(18.6 mi.)
1310 nm 18 -2 ~ +3 -23
-40 to +75°C
(-40 to 167°F)
Gigabit Ethernet 1000 Base ZX
S30-2SLC-
70
LC 2
Single
Mode
70 km
(43 mi.)
1550 nm 19* -15 ~ -8 -34
0 to +50°C
(32 to 122°F)
S35-2SLC-
70
LC 2
Single
Mode
70 km
(43 mi.)
1550 nm 19* -15 ~ -8 -34
-40 to +75°C
(-40 to 167°F)
Gigabit Ethernet 1000 Base BX
S30-1SLC/A-
10
LC 1
Single
Mode
10 km
(6.2 mi.)
1310 /
1490 nm
11 -9 ~ -3 -20
0 to +50°C
(32 to 122°F)
S30-1SLC/B-
10
LC 1
Single
Mode
10 km
(6.2 mi.)
1490 /
1310 nm
11 -9 ~ -3 -20
0 to +50°C
(32 to 122°F)
S30-1SLC/A-
20
LC 1
Single
Mode
20 km
(12 mi.)
1310 /
1490 nm
15 -8 ~ -2 -23
0 to +50°C
(32 to 122°F)
S30-1SLC/B-
20
LC 1
Single
Mode
20 km
(12 mi.)
1490 /
1310 nm
15 -8 ~ -2 -23
0 to +50°C
(32 to 122°F)
S30-1SLC/A-
60
LC 1
Single
Mode
60 km
(37 mi.)
1310 /
1490 nm
24 0 ~ +5 -24
0 to +50°C
(32 to 122°F)
S30-1SLC/B-
60
LC 1
Single
Mode
60 km
(37 mi.)
1490 /
1310 nm
24 0 ~ +5 -24
0 to +50°C
(32 to 122°F)
* Note: High Power Optic. There must be a minimum of 5 dB of optical loss to the fiber for proper operation.
Note: We recommend the use of Interlogix SFPs on the industrial managed switch. If
you insert an SFP transceiver that is not supported, the industrial managed switch will
not recognize it.
Note: Choose a SFP transceiver that can be operated under -40 to 75°C temperature if
the industrial managed switch is working in a 0 to 50°C temperature environment.
1000Base-SX/LX
Before connecting other switches, workstation, or media converter:
1. Make sure both sides of the SFP transceiver are with the same media type. For
example, 1000BASE-SX to 1000BASE-SX, 1000BASE-LX to 1000BASE-LX.
2. Check if the fiber-optic cable type matches the SFP transceiver requirement.
• To connect to 1000BASE-SX SFP transceiver, use the multi-mode fiber cable
with one side being male duplex LC connector type.
• To connect to 1000BASE-LX SFP transceiver, use the single-mode fiber cable
with one side being male duplex LC connector type.
