Interlogix NS3552-8P-2S-V2 User Manual

Chapter 6: Command line mode
NS3552-8P-2S-V2 User Manual 473
VCL MAC-based VLAN Add
Description:
Add or modify VCL MAC-based VLAN entry.
Syntax:
VCL Macvlan Add <mac_addr> <vid> [<port_list>]
Parameters:
<mac_addr> : MAC address (xx-xx-xx-xx-xx-xx)
<vid> : VLAN ID (1-4095)
<port_list>: Port list or 'all', default: All ports
Example:
Add 00-11-22-33-44-55-66 in VLAN 20 for all port
NS3552
-8P-2S-V2:/>vcl macvlan add 00-11-22-33-44-55-66 20 1-10
VCL MAC-based VLAN Delete
Description:
Delete VCL MAC-based VLAN entry.
Syntax:
VCL Macvlan Del <mac_addr>
Parameters:
<mac_addr> : MAC address (xx-xx-xx-xx-xx-xx)
Example:
Delete 00-11-22-33-44-55-66 in MAC-based VLAN list
NS3552
-8P-2S-V2:/> vcl macvlan del 00-11-22-33-44-55-66
VCL Stasus
Description:
Show VCL MAC-based VLAN users configuration.
Syntax:
VCL Status [combined|static|nas|all]
Parameters:
combined|static|nas|all: VCL User
VCL Protocol-based VLAN Add Ethernet II
Description:
Add VCL protocol-based VLAN Ethernet-II protocol to group mapping.
Syntax:
VCL ProtoVlan Protocol Add Eth2 <ether_type>|arp|ip|ipx|at <group_id>
Parameters:
<ether_type>|arp|ip|ipx|at: Ether Type (0x0600 - 0xFFFF)
<group_id> : Protocol group ID
VCL Protocol-based VLAN Add SNAP
Description:
Add VCL protocol-based VLAN SNAP protocol to group mapping.
Syntax:
