Installation Guide 63
Align the snap and notch
a) Insert  into 
b) Secure  with .
Camera Switch/Router
To install the weather resistant tape (not supplied):
1. Tightly wrap the tape around the RJ45 connector, as
shown below. Keep in mind that the tape will stretch as
you are wrapping the connector.
Cable connector
