Chapter 4: Operating instructions
18 TruVision DVR 15HD User Manual
. CD/DVD burner Insert a CD or DVD disc.
TVR 1516DHD only.
. Eject button Eject the CD/DVD disc.
TVR 1516DHD only.
. Alarm button Use to manually acknowledge an alarm.
TVR 1516DHDonly.
Table 2: Front panel button functions by task
Direction Press to cycle through channels.
Enter Press to show the PTZ control toolbar.
Reverse
Press to play the earliest video file of the current camera (upper-
left video tile if in multiview mode).
Pause
Press to freeze the last image of the live display for all active
cameras displayed.
Play Press to play 24-hour playback of the current camera (upper-left
video tile if in multiview mode).
Live Press to switch to live view mode.
Seq Press to start/stop sequencing cameras on the current monitor.
Hold the Seq button for three seconds to start and stop
sequencing.
Menu Press to enter the main menu.
Direction The left and right buttons are used to speed up and slow down
recorded video. The up and down buttons are used to jump
recorded video forwards or backwards by 30 s.
Enter Press the button to pause the video. Press again to restart the
video.
In single-frame Playback mode
, press to advance the video by a
Reverse Press to play back a camera in reverse direction.
In Picture Playback mode, view pictures in reverse direction.
Pause In Playback mode, stop playback.
Play In Playback mode, play back a camera in the forward direction.
Direction The left and right buttons are used to jump recorded video
forwards or backwards by one frame. The up and down buttons
are used to jump recorded video forwards or backwards by one
second.
Direction Press to control the movement of the PTZ camera.
Zoom +/- Press to zoom in and out.
Preset Press Preset and a numeric button to call the specified preset.
Tour Press Tour and a numeric button to call the specified shadow
tour.
