Chapter 4: Operating instructions
TruVision DVR 15HD User Manual 17
HDD: HDD indicator steady green when data is being read from or written to
the HDD. A steady red light indicates an HDD exception or error.
Tx/Rx: Steady green indicates a normal network connection. No light
indicates that it is not connected to a network.
Called “Network” on the TVR 1516DHD.
Technical Alarm: A steady red light indicates that there is a technical alarm
from the recorder. No light indicates that there is no alarm.
Called “Internal” on the TVR 1516DHD.
. IR receiver Receiver for IR remote.
To connect the remote control to the recorder, press the Device button, enter
the device address, and press Enter. See “Using the IR remote control” on
page 20 for more information.
. Live button Live: Switch to live view mode.
. Playback
buttons
Reverse: In live view mode, use to play back the earliest video. In playback
mode, playback a camera in the reverse direction.
Pause: In live view, freeze the last image of the live display for all active
cameras displayed. In playback mode, stop playback.
Play: In live view mode, play all day playback of the current camera (upper-
left video tile if in multiview mode). In playback mode, play back a camera in
the forward direction. In search mode, play back a selected video or view a
snapshot. In PTZ mode, do an auto tour.
Playback: In playback mode, start playing the current file. Starts at the
beginning of the file.
TVR 15HD only.
. PTZ buttons
Zoom +/-: In live view mode, playback mode, and PTZ control mode use this
button to zoom in and out. Also use them to navigate within menus.
TVR 15HD only.
Preset: In PTZ Control mode, press Preset and a numeric button to call the
specified preset.
Also use
to edit holiday mode, video search mode, HDD selection mode, user
management mode, bookmark management, and bookmark search.
TVR 15HD only.
Tour: In PTZ Control mode, press Tour and a numeric button to call the
specified shadow tour.
Also use to scroll between calendar months and to navigate in a text field.
TVR 15HD only.
. Direction The DIRECTION buttons are used to navigate between different fields and
items in menus.
Enter button The ENTER button is used to confirm selection in any of the menu modes.
. Archive
button
Press once to enter quick archive mode. Press twice to start archiving.
Indicator blinks green when data is being written to backup device.
. USB Interface Universal Serial Bus (USB) port for additional devices such as a USB mouse,
CD/DVD burner, or USB Hard Disk Drive (HDD).
