(A) NXG-8(E)
(B) Transformer
16 VAC, 1.5 A, 40 VA transformer. Fuse
500 mA, 250 VAC. See also
“xGenConnect Specifications” on page 2.
(C) Voltage output / Speaker output
(1) Indoor Siren/Speaker
Siren Options > Voltage Siren Output
is OFF. By default, speaker output for
15 or 20 W speaker with 4, 8 or 16 Ω
load.
(2) Voltage Output for 12 VDC indoor
siren
Siren Options > Voltage Siren Output
is ON.
Max. load = 500 mA
Requires 3.3 kΩ EOL.
(D) 2-wire smoke detector
Enable Two Wire Smoke feature
Program zone 8 as Zone type “Fire” and Zone
options “Fire”
820 Ω resistor
(E) 4-wire smoke detector
Program Zone type “Fire” and Zone options “Fire”
3.3 kΩ resistor
(F) Single zone
(1) NC contact with EOL resistor
(2) NO contact with EOL resistor
(3) One NO contact and one NC contact with EOL
resistor
(4) Zone tamper EOL resistor
See “Detector EOL Wiring” on page 23 for supported
resistor values.
(G) Doubled zone
(5) 3.74K resistors for zones 1 to 8.
6.98K resistors for zones 9 to 16.
(6) Doubled zone configuration used as a fire zone.
Upper zone (9 to 16) is not usable.
To Next Page
