xGenConnect Installation and Programming Guide 21
NXG-9 Wiring Diagram
Refer to “NXG-8(E) Wiring Diagram” on
page 17. The NXG-9 unit functionality is the
same the NXG-8 except that the
connections are spatially orientated
differently.
NXG-9 Terminals
Refer to “NXG-8(E) Terminals” on page 19. The NXG-9 unit functionality is the
same as the NXG-8 except that the connections are spatially orientated
differently.
NXG-9 LEDs
Refer to “NXG-8(E) LEDs” on page 20. The NXG-9 unit functionality is the same
the NXG-8 except that the LEDs are spatially orientated differently.
Z WAVE
ENROL
12 V 7 Ah
NXG-7002(-SIM)
J14
USBUP
ETHERNET
LAN-
OP4-
POS
COM
DATA
BELL+
OP1-
LAN+
ZONE 1
COM
ZONE 3
ZONE 4
ZONE 5
COM
ZONE 6
ZONE 7
COM
ZONE 8
AUX+
COM
ZONE 2
COM
EARTH
SMOKE-
OP2-
OP3-
AUX+
BELL-
COM
AUX+
AC
- +
TERM
J11
