Chapter 1 — Using the CV30 Fixed Mount Computer
CV30 Fixed Mount Computer With Windows CE User’s Manual 11
Understanding the Status Lights
The status lights on the CV30 turn on to indicate the status of
the network connection, a successful decode of a bar code, or a
user-defined function.
CV30 Status Lights
Understanding the CV30 Status Lights
Light Name Color Description
Battery Amber The amber light comes on when the
backup battery is critically low. You
need to replace the backup battery as
soon as possible.
Good read Green This light comes on when the CV30
successfully decodes a bar code with an
attached scanner.
Ready-to-Work
indicator™
Blue The blue light indicates when the
CV30 is ready to use in your
application, typically TE 2000. If you
have problems using the TE 2000
application, see the TE 2000 Terminal
Emulation Programmer’s Guide
(P/N 977-055-xxx).
CV30
Good read light
Ready-to-Work indicator
Battery light
