Intermec EasyCoder F2 – Installation & Operation Ed. 2 27
Chapter 4 Starting Up
If you want to use a memory card, you must insert it into the
slot in the printer's rear plate before you turn on the power. The
memory card can be an SRAM card complying with the JEIDA-4
standard or Flash Memory card from Intermec. Maximum size
in both cases is 64 Mbit (8 MB). There are three types of Flash
Memory Cards:
• A Font Card provides additional fonts as long as it remains
inserted in the printer.
• A Font Install Card permanently installs additional fonts in
the printer which can be used even after the card has been
removed.
• A Firmware Card automatically replaces the printer's fi rmware,
e.g. with an updated version.
Important!
Always turn off the power before inserting or removing a memory
card!
Do not start the printer before you have made the necessary
connections, inserted any memory card you want to use, and checked
that the printhead is lowered.
Turn on the power by means of the main switch on the rear plate.
The “Power” LED control lamp on the front panel lights up
when the power is on. Wait for a few moments, while the printer
loads the program and runs some self-diagnostic tests. Then some
kind of message will appear in the display window, depending
on startup fi le.
Power On
Memory Card
Memory Card
To Next Page
Loading...
